AR6300

Model:

AR6300 - Huawei AR6000 Series Routers

Detail:

AR6300, Huawei AR6300 Router, 1*SRU slot/4*SIC slot/2*POWER slot

List Price:

US$ 9,071.43

Price:

US$3,985.00

Delivery:

1 Month Standard Lead Time
Need it sooner? Contact our sales team.

Tags:

SIC

Add to Cart

Specification

AR6300 Specification
System Parameters
Processor	16-Core
Forwarding Performance (LAN - > WAN + WAN - > LAN,NAT + ACL + QoS,IMIX)	SRU-400H: 10 Gbps SRU-600H: 12 Gbps
IPsec performance (IMIX)	SRU-400H: 6 Gbps SRU-600H: 7.5 Gbps
Fixed WAN ports	SRU-400H: WAN: 1410GE SFP+(compatible with GE SFP) +10GE RJ45 (All WAN ports can be configured as LAN) SRU-600H: WAN: 1410GE SFP+(compatible with GE SFP) +10GE RJ45 (All WAN ports can be configured as LAN)
Fixed LAN ports	\
SIC slots	4
WSIC slots	2 (default)/4 (maximum)
XSIC slots	4 (default)/6 (maximum)
USB port	1*USB2.0
Auxiliary or console port	1 x RJ45 console port
Memory	SRU-400H: 8 GB SRU-600H: 16 GB
Flash memory	SRU-400H: 2 GB SRU-600H: 4 GB
Hot swapping	Supported
Dimensions and Weight
Router dimensions,With no mounting bracket installed (H x W x D)	130.5 mm x 442 mm x 470 mm
Router dimensions,With mounting bracket installed (H x W x D)	130.5 mm x 482.6 mm x 470 mm
Packaging dimensions (H x W x D)	201 mm x 573 mm x 640 mm
Rack	IEC
Occupied rack space	3U
Power Specifications, Power Consumption, and Heat Dissipation
Rated input voltage range (AC)	100 V to 240 V
Rated input frequency (AC)	50 Hz/60 Hz
Maximum input voltage range (AC)	90 V to 264 V
Maximum input current (AC)	5 A
Maximum output power (AC)	350 W
Power supply redundancy	Hot-swappable dual power supplies
Typical power consumption	130 W
Maximum power consumption	275 W
Fan module	Independent pluggable fan modules
Airflow	Left to right
Noise level	66.1 dB
Environment Parameters
Operating temperature	0ºC to 45ºC
Operating humidity	5% to 95% (non-condensing)
Operating altitude	< 5000 m (16404.2 ft.)
Storage temperature	–40ºC to +70ºC
Storage altitude	< 5000 m (16404.2 ft.)
Software Features and Protocols
Basic function	DHCP server/client/relay, PPPoE server/client, NAT, and sub-interface management
LAN	IEEE 802.1P, IEEE 802.1Q, IEEE 802.3, VLAN management, VLAN aggregation, MAC management, STP
WLAN (AC)	AP management (AC discovery, AP access, and AP management), CAPWAP, WLAN user management, WLAN radio management (802.11a/b/g/n/ac), WLAN QoS (WMM), WLAN security (WEP, WPA, WPA2, key management)
IPv4 unicast routing	Routing policies, static routes, RIP, OSPF, IS-IS, BGP
IPv6 unicast routing	Static routes, routing policies, RIPng, OSPFv3, IS-ISv6, BGP4+
Basic IPv6 function	IPv6 ND, IPv6 PMTU, IPv6 FIB, IPv6 ACL, ICMPv6, DNSv6, DHCPv6
IPv6 tunneling	Manual tunnel, automatic tunnel, GRE tunnel, IPv6 over IPv4 tunnel, 6 to 4 tunnel, ISATAP
Multicast	IGMP v1/v2/v3, PIM-SM, PIM-DM, MSDP, MBGP, IPv6 PIM, MLD
MPLS	LDP, MPLS L3 VPN, VLL, PWE3, static LSP, dynamic LSP, MPLS TE, IP FRR, LDP FRR, TE FRR
VPN	IPsec VPN, GRE VPN, DSVPN, A2A VPN, L2TP VPN, L2TPv3 VPN
QoS	DiffServ mode, MPLS QoS, priority mapping, traffic policing (CAR), traffic shaping, congestion avoidance, congestion management, MQC (traffic classifier, traffic behavior, and traffic policy), hierarchical QoS, Smart Application Control (SAC)
Security	ACL (v4/v6), domain-based stateful firewall, 802.1X authentication, MAC address authentication,portal authentication, AAA authentication, RADIUS authentication, HWTACACS authentication, PKI,broadcast storm suppression, ARP security, ICMP attack defense, URPF, CPCAR, blacklist, attack source tracing, online behavior management, IPS, URL filtering
Management and maintenance	Upgrade management, device management, web-based network management, GTL, SNMP (v1/v2c/v3), RMON, NTP, CWMP, Auto-Config, URL-based/USB-based/DHCP deployment, NETCONF/YANG, CLI, NetStream, IP FPM, TCP FPM, TWAMP, IP accounting, NQA
Safety and Regulatory Standards
EMC standards compliance	CISPR32 Class A EN 55032 Class A CISPR24 EN 55024 ETSI EN 300 386 AS/NZS CISPR32 Class A FCC Part 15 Subpart B Class A ICES 003 Class A IEC 61000-3-2 EN 61000-3-2 IEC 61000-3-3 EN 61000-3-3 GB 9254 VCCI-CISPR32 Class A
Environmental standards compliance	RoHS REACH WEEE
Safety standards compliance	IEC 60950-1 EN 60950-1 UL 60950-1 CSA C22.2 No 60950-1 GB 4943.1

Q&A

What accessories are available for the AR6300?

Accessories for the AR6300 include additional network modules for SIC, WSIC, and XSIC slots, power supply units, and rack-mount kits.

How does the AR6300 compare to other similar products?

Compared to similar products, the AR6300 offers more slot options and flexible configurations, making it a versatile choice for enterprise networks.

What are the power requirements of the AR6300?

The AR6300 supports dual power slots which accept redundant power supply units, ensuring a reliable power source and uninterrupted operation.

Support FAQ

Warranty terms

We promise that our products are original and genuine only. Brand-new products will be brand new and sealed to ensure no malfunctions, and second-hand products will undergo strict testing before shipment.

We offer a 1-year warranty for brand-new products and a 90-day warranty for second-hand products. During the warranty period, if the equipment you purchase has any operational defects, we will replace it for you (the warranty does not cover faults caused by human damage and improper use).

Once the product malfunctions, please notify us as soon as possible, and we will appreciate your detailed description or photos.

The warranty period is calculated from the date of receipt of the goods. For any issues or inquiries regarding your purchase, please feel free to contact us via WhatsApp (+86 152 7186 6615) or Skype/Email: sales@infdevice.com
