S5130S-28S-EI

Model:

S5130S-28S-EI - S5130 Series Swtiches

Detail:

H3C S5130S-28S-EI L2 Ethernet Switch with 24*10/100/1000BASE-T Ports and 4*1G/10G BASE-X SFP Plus Ports,(AC)

List Price:

US$ 350.00

Price:

US$300.00

Delivery:

1 Month Standard Lead Time
Need it sooner? Contact our sales team.

Tags:

SFP

Add to Cart

Specification

S5130S-28S-EI, H3C S5130S Switch, 24xGE RJ45/4xGE SFP/AC Specification

S5130S-28S-EI Specifications
Port Switching Capacity	128Gbps
Forwarding capacity	96Mpps
Box Switching Capacity	336Gbps
CPU	1 Core, 800MHz
Flash/SDRAM	256MB/512MB
Latency (64byte/µs)	GE: < 5µs 10GE < 3µs
Dimensions(W× D×H)	440×160×43.6 mm
Weight	≤2.5kg
10/100/1000 Base-T port	24
SFP+ port	4
Maximum Stacking Bandwidth	80Gbps
Maximum Stacking num	9
Input Voltage	AC: Rated voltage range: 100V~240V AC, 50/60Hz
Power consumption(full configuration)	MIN: AC:9W MAX: AC:23W
Fan NUM	Fanless
MTBF(Year)	131.97
MTTR(Hour)	1
Operating Temperature	-5℃ ~ 50℃(normal operating temperature) -5℃ ~ 45℃(When using transceiver modules with maximum transmission distance < 80km) -5℃ ~ 40℃(When using transceiver modules with maximum transmission distance ≥ 80km)
Storage Temperature	-40℃ ~ 70℃
Operating & Storage Relative Humidity(noncondensing)	5% ~ 95%

Warranty terms

We promise that our products are original and genuine only. Brand-new products will be brand new and sealed to ensure no malfunctions, and second-hand products will undergo strict testing before shipment.

We offer a 1-year warranty for brand-new products and a 90-day warranty for second-hand products. During the warranty period, if the equipment you purchase has any operational defects, we will replace it for you (the warranty does not cover faults caused by human damage and improper use).

Once the product malfunctions, please notify us as soon as possible, and we will appreciate your detailed description or photos.

The warranty period is calculated from the date of receipt of the goods. For any issues or inquiries regarding your purchase, please feel free to contact us via WhatsApp (+86 152 7186 6615) or Skype/Email: sales@infdevice.com
