C9200L-24T-4G-E, Cisco Catalyst 9200L Switch, 24xGE Data/4x1G Uplink/Essentials

C9200L-24T-4G-E, Cisco Catalyst 9200L Switch, 24xGE Data/4x1G Uplink/Essentials

Model:

C9200L-24T-4G-E

Detail:

Brand new Catalyst 9200L 24-port data, 4 x 1G, Network Essentials.

List Price:

US$ 1,532.00

Price:

US$1,012.00

Delivery:

1 Month Standard Lead Time
Need it sooner? Contact our sales team.

Tags:

1G 24-Port

Add to Cart

Resources Downloads

cisco-catalyst-9200-switch-datasheet.pdf

Specification

Product Features Comparison

Parameter	Cisco C9200L-24T-4G-E	Cisco C9200-24T-E
Product Series	Cisco Catalyst 9200L (Lite)	Cisco Catalyst 9200 (Standard)
Downlink Ports	24 x 10/100/1000BASE-T	24 x 10/100/1000BASE-T
Uplink Architecture	Fixed (4 x 1G Copper)	Modular (Network Modules)
Software Tier	Network Essentials ("E")	Network Essentials ("E")
Backplane Bandwidth	56 Gbps	128 Gbps
Forwarding Rate	41.66 Mpps	190.4 Mpps
Target Use Case	Cost-effective branch access	Standard enterprise access

C9200L-24T-4G-E

Specification	Details
Product Model	C9200L-24T-4G-E
Product Type	Enterprise Switch
Network Layer	Layer 3
Switching Capacity	56 Gbps
Backplane Bandwidth	56 Gbps
Forwarding Rate	41.66 Mpps
Ethernet Ports	24 x 10/100/1000 Mbps
Uplink Ports	4 x 1G SFP
Expansion Slots	4 x mini-GBIC (SFP)
Stacking	Supported
Dimensions (H x W x D)	44.0 x 440.0 x 445.0 mm (1.73 x 17.32 x 17.52 in)
Weight	4.35 kg (9.59 lb)
MTBF	531,030 hours

Q&A

Is the C9200L-24T-4G-E stackable?

Yes. The C9200L-24T-4G-E supports Cisco StackWise-80 stacking (80 Gbps) with up to 8 members using the optional C9200L-STACK-KIT=. Catalyst 9200L switches stack only with other 9200L models.

What are typical use cases for the C9200L-24T-4G-E?

The C9200L-24T-4G-E suits wiring closets and branch offices that need standard Gigabit access ports without PoE, for example workstation and printer aggregation. For access points, cameras or IP phones choose a PoE model instead.

What software license does the C9200L-24T-4G-E include?

The C9200L-24T-4G-E ships with Cisco Network Essentials. Essentials covers standard IOS-XE Layer 2 and Layer 3 features, while Network Advantage adds advanced routing, SD-Access fabric edge and richer security features.

Support FAQ

Warranty terms

We promise that our products are original and genuine only. Brand-new products will be brand new and sealed to ensure no malfunctions, and second-hand products will undergo strict testing before shipment.

We offer a 1-year warranty for brand-new products and a 90-day warranty for second-hand products. During the warranty period, if the equipment you purchase has any operational defects, we will replace it for you (the warranty does not cover faults caused by human damage and improper use).

Once the product malfunctions, please notify us as soon as possible, and we will appreciate your detailed description or photos.

The warranty period is calculated from the date of receipt of the goods. For any issues or inquiries regarding your purchase, please feel free to contact us via WhatsApp (+86 152 7186 6615) or Skype/Email: sales@infdevice.com
